FEATURE
- Shoots fasteners up to 1-3/8"/ 35 mm length easily even in hardwood
- Narrow nose reaches tight areas and corners for detailed finish work
- Removable nose cover provides easy access for clearing jams
- Double trigger safety lock prevents accidental firing of tool
- W/Lock-out mechanism
- Fastener range: 3/8" ~ 1 3/8" (10mm ~ 35mm) excluding 1 1/4" (32mm)
SPECIFICATION
| Body Dimension | 7.75"L x 2"W x 7.5"H/ L200 x W50 x H190 mm |
|---|---|
| Weight | 2.21 lbs. (1 kgs.) |
| Load Capacity | 1 strip (approx. 100 pins) |
| Operating Pressure | 60 ~ 100 psi (4 ~ 7 bars) |
| Fastener Type | 23 Gauge Headless Pins |
| Fastener Range | 3/8" ~ 1 3/8" (10mm ~ 35mm) excluding 1 1/4" (32mm) |
| Air Inlet | 1/4" (6mm) NPT male plug |
